Kernom RIDGE Overdrive Guitar Pedal

Struggling to find the perfect overdrive? Whether you need a clean boost, a transparent overdrive, or high-gain distortion, RIDGE gives you a seamless spectrum of tones—all in one pedal.

From Klon-like transparency to Tube Screamer warmth, from bluesy edge-of-breakup tones to modern high-gain saturation, RIDGE eliminates the need for multiple pedals. Dial in your perfect drive with the MOOD knob.

Features:

• From Clean Boost to High Gain, from transparent boosts to saturated overdrive
• Seamlessly blend between legendary overdrive tones.
• Advanced EQ to shape your tone pre and post clipping
• Expression Pedal Input for real-time control
• True Bypass
• Expression input
• MIDI In/Out
• 1 Internal favourite preset
• 127 MIDI presets
• 30V output voltage swing capability
• Premium input stage with sensitivity adjustment
• Ultra-low noise output
• 5mm thick touring-ready casing

Specifications:

• Input Impedance:  1Meg Ohm (Guitar mode) / 32k Ohm (Line mode)
• Output Impedance: 100 Ohm
• Bypass: True Bypass (electromechanical relay switching)
• Chassis: 5mm thick aluminium casing with summit white smooth and high-grade painting surface
• MIDI: Use a type A mini jack TRS MIDI cable.
• Power: Use an adaptor (not included) with the following rating: 9VDC centre negative
• Current Draw: 250mA minimum, 300mA or more recommended
• Dimensions:  11.2 cm deep x 16.4 cm wide x 5.2 cm tall (4.4 inches deep x 6.5 inches wide x 2 inches tall).
• Weight: 850 g (1.8 lbs)
